SPECIFICATIONS
| PIPE SIZE | Rc1/4 for IN port, Rc1/8 for sensing port | |||
| FLUID |
Compressed air filtered by 5μm filter element (No oiliness) |
|||
| OPERATING PRESSURE | 0.2MPa ……Supply pressure | |||
| AMBIENT TEMPERATURE | 5 ~ 50°C | |||
| ELECTRICAL CONNECTIONS |
Economiter: MVS-214-02KS-07 • DIN type Pg 11 (for cable dia. of 6 ~ 10mm) Air limiter: S51 series •G1/2 for conduit (Std.) Optional capcon or cordlock available |
|||
| MAX. STACKING | Up to 3 Air limiter units | |||
| MASS(kg) |
1.93kg /with 3 units 1.43kg /2 units 0.93kg /1 unit |
|||
| FOR ECONOMITER | ||||
| RATED VOLTAGE |
• AC 100V 50/60Hz, 110V 60Hz • AC 200V 50/60Hz, 220V 60Hz • DC 24V |
|||
| VOLTAGE ALLOWANCE | –15 ~ +10% | |||
| INSULATION CLASS | B | |||
|
SOLENOID HOLDING CURRENT (INRUSH) |
― | 50Hz | 60Hz | |
| AC 100V | 0.102 (0.165) A | 0.079 (0.140)A | ||
| AC 200V | 0.049 (0.080) A | 0.039 (0.068)A | ||
| DC 24V | 0.27A | |||
| FOR AIR LIMITER | ||||
| TYPE OF SWITCH | Small current type | High sensitive type | ||
|
CURRENT CAPACITY OF SWITCH |
AC 100V | 1 ~ 100mA | 30 ~ 100mA | |
| AC 200V | NA | 20 ~ 100mA | ||
| DC 24V | 1 ~ 100mA | 35 ~ 100mA | ||
